RIGOL DS1074Z-S DIGITAL OSCILLOSCOPE

[kalimero]

Po dveh mesecih čakanja končno pri meni. Par tehničnih specifikacij:


4 channels.
Bandwidth up to 70 MHz. Sample rate up to 1 GS/s.
Up to 12 Mpts memory depth, optional up to 24 Mpts.
Up to 30,000 Wfms/s waveform capture rate.
Optional realtime waveform record and replay up to 60,000 frames.
Optional serial bus triggering and decoding (RS232, I2C, SPI).
Models "-S": Built-in 2-channel 25 MHz signal source: 200 MS/s sample rate, 14 bit vert. resolution, standard waveforms sine, square, pulse, triangle, noise, DC, arbitrary waveforms: Since, exp. rise/fall, ECG, Gauss, Lorentz, Haversine.
Interfaces: USB (host and device), LAN (LXI-C), optional GPIB.
7 inch WVGA TFT display (800X480)
Compact and portable.




Zdaj moram pa sam še kaj zlotat skupaj.
